Power cables

Name: Power cables
SKU: 0

A power cable is a type of cable composed of a conductor (usually copper or aluminum), an insulation layer, and a sheath. Its function is to transmit and distribute electrical energy. They are typically laid underground, in cable trenches, conduits, or inside buildings to form a power transmission system.

Email : emma@sdbcgroup.com

WhatsApp : +8618865129663

Product Parameters

PVC insulated and PVC sheathed non-armored power cable

PVC insulated and PVC sheathed armored power cable

XLPE insulated PVC/LSOH sheathed power cable

LSOH insulated cable

Flame-retardant and fireproof power cables

Medium-voltage power cables

Power cable with PVC insulation and PVC sheath
rated voltage	300/500V , 600/1000V or 1900/3300V

conductor material	multi strand annealed copper
insulation material	Flame-retardant polyvinyl chloride compounds
infilling	Polyvinyl chloride or polypropylene
wrapping tape	polyester (mila) tape
outer sheath material	Flame-retardant polyvinyl chloride mixture

Conductor color
Insulation color	1 core	Red, yellow, blue, black, yellow/green, or other colors specified by the customer
	2 cores	Red and Black
	3-core	Red, yellow, and blue
	4 cores	Red, yellow, blue, and black
Sheath color	Black, gray, white

testing standard
size of product	material standards	flame retardant delay test
BS 6360	BS 7655	BS 4066 PART 1
BS 6004	IEC 60811	IEC 60332-1
IEC 60227-3	.	.
IEC 60228	.	.
IEC 60502-1	.	.

Model	Number of cores	Rated voltage UO/UKV
		3.6/66/6	6/108.7/10	12/2018/20	21/3526/35
		Conductor Nominal Cross-sectional Area (mm²)
YJLV YJV YJLY YJY	1	25-500	25-500	35-500	50-300
YJLV32YJV32YJLY32JYY32	1	25-500	25-500	35-500	50-300
YJLV42YJV42YJLV43YJV43	1	25-500	25-500	35-500	50-300
YJLVYJVYJLYYJY	3	25-300	25-300	35-300
YJLV22YJV22YJLV23YJV23	3	25-300	25-300	35-300
YJLV32YJV32YJLV33YJV33	3	25-300	25-300	35-300
YJLV42YJV42YJLV43YJV43	3	25-300	25-300	35-150
